150 - Rotating locked wheel does not cause the chassis to rise.
But, when the brakes are applied, the difference is dramatic -- the chassis does not rise because the two arms act to transmit the torque generated by the brakes into the chassis, to be counteracted by a vertical force at the front wheel -- increasing its loading and braking capability. BE SURE TO SEE THE 3 ADDED PHOTOS!
 |
|
 |
